While the principle is the same in the processing of the black sand, gold concentrates, in small and larger quantities, the method, and equipment is adapted to the quantities involved. Both sample size, and production size, are discussed in this study.
First, let us deal with the small quantity, or pan, sample situation where you have only a limited amount, perhaps the result of a half dozen pans, and where you wind up with approximately a pint of concentrates. This will give us a method and demonstrate the same principles that will be Involved in the larger quantities.
Assume you have already picked out the nuggets and coarse gold, and have just the black sand and ftne gold remaining. Here is one way to proceed:
1. Spread it all out in your pan, a pie tin, or a plate, and set it in the sun, or on a source of heat such as a radiator or stove to dry.
2. When dry, you can put a small quantity at a time on a piece of stiff cardboard and blow across the material, perhaps tapping the card board a little, gently, and you will ftnd that a good share of the lighter-weight sand will blow off at once. As you stir it around and blow again, you will get rid of a little more, but there will still be a quantity left. That remaining is probably one or more of the iron containing black sands.
3 . Since most of these compounds are magnetic they can be readily picked up with a magnet.
Some of the black sand will stick to the magnet in spite of every thing you can do. Fortunately, this can be prevented by wrapping the magnet with a sheet of plastic before using. The black sand will cling to the plastic but will drop off as soon as the magnet is removed.
4. If there is still black sand of a non-magnetic type mixed with the gold, then your next step is to separate the gold with the aid of mercury by a simple process called amalgamation.
Before proceeding to the second step of separating the gold from the black sands, the concentrate must be thoroughly cleaned. The necessity for this preliminary step before amalgamation is attempted cannot be overemphasized. In discussing the amalgamating powers of mercury in a placer gold washing plant with a consulting engineer recently, I was surprised when he said, "from my experience, the amount of fine gold crossing a mercurycoated plate that is actually recovered is comparatively small - perhaps 10 to 15 percent. He explained the reason the percentage is so low is that practically all placer gold has a protective coating of some kind, perhaps pine oil, if in a mountain country. Unfortunately, gold is often coated with various substances, such as iron sulfide, magnesium, rust, or other inorganic amalgamation. Explaining further he said, the answer is to treat the sand containing the gold with a cleaning substance before it comes into contact with mercury." This is extremely valuable Information and has to do with the over-all recovery ratefrom any placer gold recovery system or operation.There are other ways of cleaning gold, but one very simple method employs the use of nitric acid. First,place the concentrated, gold-bearing sands into a plastic gold pan or other container that will not be affected by strong acids. Cover the concentrates with about a half inch of water and add the acid in small amounts until a slight boiling action occurs. This boiling begins when about a 90 percent concentration is reached. In some cases, no dilution is necessary. Add straight acid. Mix the acid solution around for several minutes, making sure all the material is well saturated. Even better, let it stand a while. The acid solution is then poured off and the concentrate rinsed by dipping- the pan in the stream. The gold is now ready for amalgamation.
Amalgamation takes place when the two metals are brought into contact with each other by mldng or blending, and even the smallest particles of flour gold is gathered up and absorbed by the mercury. This special affinity for gold makes mercury an invaluable aid in separating the gold from the black sands.
It takes only a few drops of mercury to gather the gold in the black sand found in an average pan of sample. The mercury should be agitated with the concentrate under water until every portion has been contacted and all the slall globules and BBs of mercury absorbed by the one ball of amalgam. It now contains all the flne, and flour gold that would otherwise have been lost. Part # 1: Quite frequently, more mercury win be applied than is required for the amount of gold to be absorbed, in which case the ball of "amalgam' will actually be a mixture offree mercury and the amalgamated substance. In fact, it is desirable that an excess of mercury be used to assure that all the free gold in the sample is absorbed. However, in the interest of economy, and the conservation of mercury, a preliminary step is required before beginning the separation of the gold from the amalgam. This consists of removing as much of the free mercury from the amalgam as possible. This can be accomplished in several ways. Historically, the mcrcury-amalgam mixture was squeezed through a piece of chamois skin, or a sflk cloth, but this created problems. More recently, a syringe, with a thin, cotton pad in front of the plunger head, is being used with great success. The mercuryamalgam mixture is placed in the syringe and, upon pressure, the mercury is squeezed through the cotton pad into a container, leaving the small, round, cake or wafer of amalgam in the syringe. The cake of amalgam is now ready for further treatment.
PART #2: The next step is to be conducted out-of-doors, as toxic fumes are produced. It is suggested that you set up a stool, chair or small table in your back yard, or other open area, then place an electric hot plate, with a long extension cord attached, on the table. Place a Pyrex dish 2/3 full of 25 to 65 percent nitric acid on the hot plate. Ordinary glass will break upon heating, so the dish must by Pyrex, which is made to withstand heat.
You are now ready to place the cake of amalgam in the solution. Almost at once, you will note a reaction taking place as fumes begin to rise. These fumes may not be fatal, but are toidc and, ifinhaled, may make you sick andcause damage to your lungs, so stay away from them. Take no chances. Next, you turn the current on to the hot plate, and let the solution boil for 5* minutes. What is the mercury from the amalgam is being taking place is,
absorbed, or taken into solution by the nitric acid an leaving the free gold in a natural form. At the end of 5 minutes, turn off the current and, after the dish has cooled and no more fumes coming off, walk over and inspect your cake Of gold- Pick it out of the solution with and drop it into a cup Of water with a pair of pliers natc of soda in it to neutralize the acid on ordinarybicarbo r, or cake, of gold is not solid, it. you will note the little wafer but rather looks like a sponge
After the mercury was absorbed by the nitric acid, it left empty spaces where the mercury had been, giving the remaining gold a sponge-like appearance, drab and rusty or. In fact, it'-s calledtsponge gold and is ready to be in col
melted down into a bar, or used for any purpose desired.
Heating the sponge blowtorch temperature will bring out
the natural, bright gold color.
Incidentally, you should have a half gallon or more of water and bicarbonate of soda mixture available in case you get some of the acid on your hands and clothes. If you should get acid on your hands, dip them in the soda water immediately.
Part #3: The remaining nitric acid solution now contains the small amount of mercury which came from the amalgam. This mercury can be recovered by placing a small sheet or bar of copper in the solution. The mercury will collect on the copper and can be scrapped off and saved for future use.
The used nitric acid solution should be diluted and
neutralized by adding soda water then flushed away.Itmust not be put through the plumbing system unless diluted and neutralized. The acid solution can be saved and re-used again, but nitric acid is not so costly that this seems necessary.Boil gently; don't deplete the quantity of acid more than a third. Put a Pyrex dish 2/3 full of 25 to 65 per cent nitric acid on a table in your back yard, or other open area. The fumes are very toxic-take no chances. IN MY OPINION
As a prospector I have seen equipment of all shapes and size some of it good and some not so good. As a rule the simpler it is the better it works. In most cases the makers of high bankers and dredges will get so rapped up in making the almighty dollar that they louse sight of what keeps a product selling. There are three things that you should first look for when you choose a piece of equipment.
1. Will this equipment do what it is suppose to do, and do it in an efficient manner?
2. Is the equipment maid with Quality materials and workman ship, and will it be durable and last for many years?
3. How versatile is this equipment, and how portable is it?
Once you have studied a piece of equipment and answered these Questions, you will usually walk to another and start the procedure all over again. Because there are only a hand full of products on the market to day that will let you answer yes to all those Questions with out hesitation.
Now if I may I would like to give you MY OPINON on such a piece of equipment. THE HONCOOP HIGHBANKER
The HONCOOP HIGHBANKER is the only highbanker, on the market that employees all the basic concepts which will allow you not only to catch the fine microscopic gold but it also lets you find nuggets and coarse gold better than any thing on the market.
The materials that this highbanker is maid of are all aircraft aluminum and Uses stainless steel screws and fasteners. Parts that well get broken from time to time are maid of materials that you can easily pick up at your local hardware, you won’t have to worry about weather you can find them or not.
The percentage of recovery is so great that after you have done a week or so of high banking and gather your concentrates you can run them through your bottom tray and concentrate them down even father with out fear of lousing gold or black sand making less material to take home, but making your recovery rate much higher.
This highbanker can be used in several various situations .You can Take out the top tray and use it in a creek as just a sluice box and will catch both course and fine gold better than any other on the market, but dose run a smaller amount of material per hour due to its smaller size. Once you have finished using it in that manner you may take out the riffle section and the miners moss and use it as mini sluice and separate your visible gold from your black sand.
If you happen to be in Alaska or any beach along the Organ and California coast line or where ever you think that their might be beach gold You have the best beach box on the market to day, If you want to go dredging you can convert it over to a dredge with the dredge kit for a small fee and have the same percentage of recovery as in the highbanker mode. I know of no other highbanker on the market that will do all these things and do them efficiently. I highly recommend this Honcoop Highbanker, for the serious prospector.
