IS THE PATTERN OF RAINFALL IN ISRAEL AFFECTED BY THE ASWAN HIGH DAM ?
URI BATZ
Israel Meteorological Service
From the end of the 1960's, changes took place in the spatial distribution and quantity of precipitation in Israel, which are difficult to attribute solely to random fluctuations. A downwards trend in the quantity of precipitation in the northern part of Israel, whereas an upwards trend in the quantity of precipitation in the central and southern part of Israel began to appear (Steinberger and Ya'ari-Gazit, 1992).
Parallel to these changes the Aswan High Dam project was completed in Egypt. Its first stage was completed in 1964 and the dam was fully operational in 1970 , and as such clearly serves as an excellent example in its effect upon the ecological balance in the area .
The key question which must be posed is : has the operation of the Aswan Dam affected the Israeli rainfall pattern?
The dam has severely reduced the flow of the river Nile. Before its construction , an average of 40 billion cubic meters of water flowed to the Mediterranean each year, whereas after it was completed the flow was reduced to 3 billion cubic meters (Wadie,1984;Sharf El Din, 1977).
These alterations in flow have also affected the Mediterranean . Oceanographic studies have shown that the thermal and saline levels in the south-eastern region of the Mediterranean have changed.(Hecht, 1992; Wadie,1984; Gerge,1976).
It is reasonable to suggest that the changes in the thermal structure of the sea have led to alteration in the positions of the winter pressure systems in its southern region. In turn , this situation has influenced the amount and pattern of rainfall in Israel, which also was affected by the global climate (Cohen,1991;Steinberger and Ya'ari-Gazit,1992).
We are faced with an overall picture of rainfall completely different from which we have been accustomed to seeing in the past. This picture is highly significant and to my opinion holds critical implications from the hydrological aspect and for the balance of water resources in Israel. This means that there is a higher probability of winters in which there will be less rain in the north than the average , and since Israel's main water sources are situated in the north, there is a possibility of damage being caused to the balance of water resources in Israel.
This paper is about the range of issues , climatic and oceanographic , influencing the rainfall in Israel ,pre and post the construction of the Aswan High Dam in Egypt.
Satellite thermal analysis, shows warm and cold water
in the eastern Mediterranean .the warm water are in turquoise and the colder
are in gray.
.
Appendix
For a better orientation I am including a satellite image2
of Israel
with some details about the places I mentioned in the paper. The research
was completed in 1995 and since then the rainfall trend between the years
1995-1998 was as I found in my work except the rainfall amount in the year
1997\1998 when the central part of Israel received
90-95% rainfall ,from the average, and the northern
part of Israel( Zefat is the station which represents the
northern mountains) received 110-120% rainfall from
the average which is opposed to my theory. I assume it happened due to
El-Ninio phenomena, which caused a slight rise in the sea surface temperature (sst) in the East
Mediterranean.
PLACES | Long.E | Lat.N | Elevation
in meters |
Yearly average
Rainfall in mm |
ZEFAT | 3530 | 3258 | 930 | 718 |
JERUSALEM | 3513 | 3147 | 810 | 554 |
NAHARIYA | 3506 | 3301 | 10 | 640 |
GAZA | 3428 | 3130 | 7 | 410 |
