1. 2 spoke steering-wheel diameter 39 cm. Steering-wheel rotation: 4 1/2 turns Indicator-switch with automatic return
2. Ignition-lock with three positions: "marche" ignition on, key blocked in the lock, "garage" ignition off. key removable, steering-wheel not blocked, "stop" ignition off, key removable, steering-wheel blocked
3. Ignition-lock (if assembled)
4. Indicator-switch (if assembled)
5. Red indication-light for oilpressure en water-temperature
6. Speedometer with a day- and total distance counter
7. Green indication-light for dynamo/contact combined with petrolgauge.
8. Content petroltank: 27 litre
9. Parkinglight-switch (if assembled)
10. Lightswitch (if assembled)
11. Air intake
12. Dashboardlocker (non lockable)
13. Screen-wiper switch. Electric screen-wiper, in case of vailure manual useable.
14. Combined light- and klaxon switch
15. Clutch
16. Hydraulic brake pedal working on front- and rear wheels.
17. Accelerator
18. Gear-lever
19. Handbrake, mechanical working on rear-wheels and startbutton. Before starting pull up the ring.
20. Choke
21. Diagram (see 18 as well )
