Specifications
Type | two-seat long-rang interdiction aircraft with interceptor varient |
Contractor | Panavia |
Country of Origin | Great Britain/Germany/Italy |
Powerplant | two Turbo-Union RB.199-34R Mk 104 turbofan engines |
Thrust | 16,075lbs reheated each |
Length | 59ft 4in |
Height | 19ft 6.25in |
Wingspan | 45ft 7.75in spread 28ft 2.5in |
Wing Area | 286.3 Sq. ft |
Max Speed | 1,453mph (mach 2.2) @ 36,090ft |
Climb Rate | 50,000ft/minute |
Service Ceiling | 70,000ft |
Range | 460 mile radius on two-hour patrol |
Empty Weight | 31,970lbs |
Max Take-Off Weight | 61,700lbs |
Armament | up to 12,800lbs of : |
