SU-24 FENCER

Specifications
Typetwo-seat close strike/attack plane
ContractorSukhoi
Country of OriginUSSR
Powerplanttwo Lyul'ka AL-21F-3A turbojet engines
Thrust24,802lbs reheated each
Length69ft 10in excluding probe
Height19ft 8in
Wingspan57ft 5in spread
34ft 5.5in swept
Wing Area505.9 Sq. ft
Max Speed1,439mph (mach 2+) @ 36,090
Climb Rateunknown
Service Ceiling57,415ft
Range650 mile radius
Empty Weight41,888lbs
Max Take-Off Weight87,520lbs
Armament
  • one 30-mm GSh-23-6 cannon
    up to 17,635lbs on 9 external pylons of:
    air-to-air & air-to-surface missiles,
    guided & cluster bombs, dispenser weapons, large-calibre
    rockets & rocket-launcher pods, drop tanks, & ECM pods
