THE ZACKLIFT Z18 FRAMELIFT |
The Z18, with 18,000 pound rating, is available
in a 86" reach. Feature Standard Mounting. |
|
Specifications |
Z18-86" |
|
Retracted lift rating |
18,000lbs |
|
Extended lift rating |
13,000lbs |
|
Tow rating |
85,000lbs |
|
Weight of Unit |
1,500lbs |
|
A. Retracted distance |
52" |
|
B. Reach |
86" |
|
C. Reach with 12" Bus Extensions |
98" |
|
D. Approx. reach, center of axles to
forks |
141" |
|
E. Distance from tailboard when stored |
10" |
|
F. Upward tilt, max. lifting height |
22deg.-62" |
|
G. Tilt below ground |
8deg.-6.5" |
|
H. Downstroke on lift cylinder |
17" |
|
