986104 AIR FLOW HEATER
12,
Install water hose, clamps and bracket as
shown, making sure
that the upper hose at
"B" on engine is
connected to the lower
pipe at heater,
(see figure 91). Dimples in
air duct are provided
to locate position for
drilling bracket
holes, (see figure
95).
Figure 95
13.
Install stop as shown in view "M" by re
moving screw, place stop in position then
replace screw,
(see figure 90).
|
Figure 96 |
|
|
14. Refill radiator while engine is running to |
|
|
eliminate trapping air in heater system. |
1. Remove cover plate from right-hand inside |
|
15, Make sure that operating instruction tag is |
cowl panel. Remove round cover plate front |
|
furnished to the customer. |
the right-hand side of the front of dash and |
|
cut hole in dash mat to match, (see figure |
|
|
97). |
|
|
Approximate Flat Rate Time 1.3 hours. |
2. Cut two holes in dash mat for water hose |
Procedure
for Installation of Air Flow Heater
on All Model Trucks.
(Special Instructions for Cab Over Engine
Models)
