Buddy Controller Card
Specification |
|
|
Bus
Interface: |
PCI bus
V2.1: 5V, 32bit, 33MHz |
|
Data Transfer
Rate: |
Up to
132MB/sec |
|
Video Driver
Interface: |
Compatible with Trident's RAM BIOS and Win95/98
Driver |
|
Communications
Cable: |
Category
5, standard ethernet pin out, with RJ-45 connectors |
|
Max.
Controllers: |
Four
Buddy controller cards supported (depends on available PCI
slots) |
|
Dimensions: |
6.5" x
4.0" (16.5cm x 10.1cm) |
|
Hardware
Layout: |
Single-sided |
|
Weight: |
3oz |
|
Power
Consumption: |
7W
(includes power required for controller card and junction
box) |
|
DIP Switch: |
1 x
2-switch DIP switch bank to accommodate different motherboard
initialization event counts. (0,4,8,64 counts) |
|
Agency
Approval: |
FCC Class
B, CE |
|
|
|
Video
Specifications |
|
|
Video Chip: |
Trident
3D image T9750 graphics chip
This is a 2D/3D graphics accelerator
chip. |
|
4MB of SGRAM: |
Supports
1280 x 1204 x 16bit colours at 60Hz (true colour)
Supports 1024
x 768 x 32bit colours at 75Hz (true colour)
Supports 800 x 600 x
32bit colours at 85Hz (true colour)
Supports 640 x 480 x 32bit
colour at 85Hz (true colour) |
|
|
|
Buddy Junction Box
Specifications |
|
|
Transmission
Distance: |
50ft
maximum |
|
Transmission
Medium: |
CAT-5
(shielded, twisted pair with RJ-45 connectors) |
|
Dimensions: |
3.35" x
1.38" x 5.12" (8.5 x 3.5 x 13.0cm) |
|
Power of
Peripherals: |
0.1A
(maximum) |
|
Weight: |
Less than
1lb |
|
Agency
Approval: |
FCC class
B, CE |
|
Miscellaneous: |
Contains
1 LED for system status monitoring
Contains 1 buzzer for audible
error detection and system initialization monitoring |
|
|
|
Peripherals
Requirements |
|
|
Monitor: |
Super VGA
HD15 female connector |
|
Keyboard: |
Mini-DIN
connector |
|
Mouse: |
Mini-DIN
connector |
|
Cable: |
Communication signal port (RJ45/ethernet
pin-out) |
