New GM Front Drive Shafts |
|
Shaft Number |
Vehicle |
Trans/Comment |
YEAR |
U-Joint |
DIA" |
F To F |
|
MD-NGM0001 |
Astro/Safari |
Weld-Weld 19 5/8" |
92-98 |
CV |
2.0" |
31 1/8 |
|
GM Front Drive Shafts |
|
Shaft Number |
VEHICLE |
Trans/Comment |
YEAR |
U-Joint |
DIA" |
W To W |
|
MD-GM0001 |
S10/Bravada |
Code MC6 Also #15762969 |
00/01 |
CV/1310 |
1.25" |
18 7/8" |
|
MD-GM0002 |
Envoy/TrailBlazer |
Code HA1 Also #15113797 |
02/04 |
CV/1310 |
2.0" |
26.75" |
|
MD-GM0003 |
S10/Bravada |
4WD OPT Code NP8 Code on Shaft ND9 |
99/04 |
CV/1310 |
2.0" |
21.0" |
|
MD-GM0004 |
S10 4WD |
Option CodeNP1 Code on Shaft ND8 |
99/04 |
CV/1310 |
2.0" |
20.25" |
|
MD-GM0005 |
S10 4WD |
Also #26032451 |
95-99 |
CV/1310 |
2.0" |
20.5" |
|
MD-GM0006 |
TrailBlazer |
Code JRO Also #15113798 |
02/04 |
CV/1310 |
2.0" |
20.5" |
|
Ford Front Drive shaft |
|
Shaft Number |
VEHICLE |
Trans/Comment |
YEAR |
U-Joint |
DIA" |
Flat To Flat |
|
MD-F1301 |
Ford Explorer/ Mercury Mountaineer |
4 DR. 8CYL 22.25" Weld-Weld |
97-01 |
CV/ 1310 |
1.75" |
|
|
MD-F1302 |
Ford Explorer/ Mercury Mountaineer |
4.0L 24" Weld-Weld-Mountaineer |
97-01 |
CV/ 1310 |
1.75" |
|
|
MD-F1303 |
Ford Explorer/ Mercury Mountaineer |
5.0L 23" Weld-Weld-Mountaineer |
97-01 |
CV/ 1310 |
1.75" |
|
|
MD-F3101 |
Ford Explorer/ Mercury Mountaineer |
4 DR. 8CYL 22.25" Weld-Weld |
02-03 |
1310/CV |
1.75" |
|
|
MD-F3102 |
Ford Explorer/ Mercury Mountaineer |
4.0L 24" Weld-Weld-Mountaineer |
97-05 |
1310/CV |
1.75" |
|
|
MD-F3103 |
Ford Explorer/ Mercury Mountaineer |
5.0L 23" Weld-Weld-Mountaineer |
97-01 |
1310/CV |
1.75" |
|
|
Jeep/Dodge Front Drive Shafts |
|
Shaft Number |
VEHICLE |
Trans/Comment |
YEAR |
U-Joint |
DIA" |
C To C |
|
MD-JD0001 |
Gr. Caravan |
AWD Rear 1/2 Of 2 Pc. Shaft |
01-03 |
CV |
2.50" |
33.50" F-F |
|
MD-JD0002 |
Grand Cherokee |
6 & 8 CYL. At 231/242/249/ TC DANA 30 C-C 30.75" |
93-95.5 |
CV/1310 |
1.75" |
31.7/8 F-F |
|
MD-JD0003 |
Dodge |
Pickup 2500/3500 5.2L, 5.9L MT DANA 60 |
94-99 |
1330CV/7290 |
2.50" |
29.5 C-C |
|
MD-JD0004 |
Grand Cherokee |
4.0L 5 SPD Mt 231 TC, DANA 30 FRT |
92.5-95 |
CV/1310 |
1.75" |
30.0" F-F |
|
MD-JD0005 |
Wrangler |
4.0L 5 SPD Mt 231, 242 Extension less TC |
97-01 |
CV/1310 |
2.50" |
40.0" C-C |
|
MD-JD0006 |
Wrangler |
2.5L & 4.0L AT, 4 SPD MT DANA 30 231/242 TC |
97-01 |
CV/1310 |
1.75" |
38.25" |
|
MD-JD0007 |
Grand Cherokee |
Grand Cherokee 5.2L, 249 TC, DANA 30 |
95.5-98 |
CV/1310 |
1.75" |
31.25" F-F |
|
MD-JD0008 |
Grand Cherokee |
5.2L Engine W/At 249 TC, DANA 30 |
95.5-96 |
CV/1310 |
1.75" |
32 7/8"F-F |
|
MD-JD0009 |
Grand Cherokee |
4.0L AT 242 TC |
96-98 |
CV/1310 |
1.75" |
33.00" F-F |
|
MD-JD0010 |
Grand Cherokee |
4.0L, AT |
96.5-97 |
CV/1310 |
1.75" |
31.25" F-F |
|
MD-JD0011 |
Dakota |
|
97-99 |
CV/1310 |
1.75" |
26 1/2" |
|
MD-JD0012 |
Dakota/Durango |
W/AT Has Flange On Front |
97-00 |
CV/1310 |
1.75" |
23.5" |
|
MD-JD0013 |
Grand Cherokee |
5.2L Engine W/AT 249 TC, DANA Model 30 Front Axle |
96 |
CV/1310 |
1.75" |
30.75" F-F |
|
MD-JD0014 |
Grand Cherokee |
4.0L AT 249 Transfer Case |
96-98 |
CV/1310 |
1.75" |
33.50" F-F |
|
MD-JD0015 |
Grand Cherokee |
8 Cylinder |
99-00 |
CV |
1.80" |
33.25" F-F |
|
MD-JD0016 |
Grand Cherokee |
6 Cylinder |
99-00 |
CV |
1.80" |
34.5/8" F-F |
|
MD-JD0017 |
Grand Cherokee |
Front 4.7/5.7L |
05 |
CV/1310 |
2.0" |
34.50" F-F |
|
MD-JD0018 |
Dodge |
Pickup 2500/3500 5.9L Diesel/8.0L HD AT DANA60 |
00-02 |
1330CV/1330 |
2.50" |
|
|
MD-JD0019 |
Grand Cherokee |
4.0L |
02-04 |
CV/1310 |
1.75" |
34 5/8" F-F |
|
MD-JD0020 |
Dodge |
2500/3500 5.9L Diesel, 8.0L MT 9.25 Rear Serrated |
03-04 |
1330CV/1330 |
2.5" |
|
|
MD-JD0021 |
Dodge |
2500/3500 5.9L Diesel, 8.0L AT 9.25 Rear Serrated |
03-04 |
1330CV/1330 |
2.5" |
28.5" |
|
MD-JD0022 |
Dakota |
Man Trans |
97-05 |
CV/1310 |
2.0" |
24.0" F-F |
|
MD-JD0023 |
Durango |
Also 01-05 Dakota AT |
01-03 |
CV/1310 |
2.0" |
26.75" F-F |
|
MD-JD0024 |
Dodge |
Ram1500 PU AT, 8.25 Rear |
02-05 |
CV/1310 |
2.0" |
26.75" F-F |
|
MD-JD0025 |
Liberty |
Liberty 2.8L AT |
04 |
CV |
1.80" |
33.25" F-F |
|
MD-JD0026 |
Liberty |
Liberty 3.7L |
02-04 |
CV |
1.80" |
|
|
MD-JD0027 |
Grand Cherokee |
V8 At & 01 + Liberty |
03+ |
CV |
1.80" |
32" F-F |
|
MD-JD0028 |
Durango |
With 244 Transfer Case |
05 |
CV/1330 |
2.37" |
34 3/8" F-F |
|
MD-JD0029 |
Grand Cherokee |
4.7L |
02-03 |
CV/1310 |
1.75" |
32.0" C-C |
|
MD-JD0030 |
Jeep |
Cherokee 4 Spd AT DANA 30 Front Axle |
90-00 |
CV/1310 |
2.0" |
30.5" |
|
MD-JD0031 |
Dodge |
1500/2500/3500 PU 5.9L DANA 44 3500/3850# Axle |
94-97 |
1330CV/7290 |
2.50" |
33.25" C-C |
|
MD-JD0032 |
Grand Cherokee |
5.2L 231 TC DANA 30-34 3/8" F-F |
93-95.5 |
CV/1310 |
1.75" |
33.0" |
