punch location for the two Bracket holes and
drill through with No. 29 or 9/64" drill.
DO NOT TAP HOLES

Reassembling Handle Unit To Shaft

10. Be sure to turn Switch to "OFF" position
(see figure 169). This must be done to avoid
damage to Switch contact.

11. Slide Housing "E" into position on Shaft.
DO NOT FORCE ASSEMBLY, as force may
bend or damage driving Racks.

12. Start Screw "A" into Housing "E." DO NOT
TIGHTEN. Screw should be in approximate
center of locating groove in bottom of Shaft.
13. Insert Pinion *'D" between teeth of driving
Racks in Housing "E." BE SURE that Pinion
is started into center of hole in Housing
"E." Pinion should slip into place easily
under very light finger pressure. If more
than light finger pressure is required, PiD
ion is not assembled into center of hole (see
figure 168).

Figure 172
